TECHNOLOGY
Inkjet
DigiDot drop-on-demand, piezoelectric
Ink
Water based dye and pigment, InkSafe™ technology (contact your local sales representative for details)
Drop Sizes
Variable, 5–12 picoliter
Operating
Next generation look & feel user interface
Paper Transport
Pinless, tight web, automatic tension control
Paper Input
Tight web unwinder (included in basic unit)
Paper Output
Open post-processing interface with Type1 connectivity
Print Resolution
1200 dpi perceived image quality with 600 × 600 dpi and Multilevel
Page Composition
Simplex configuration: 2-up simplex
I-Twin / L-Twin / H-Twin: 2-up duplex
Print Speed A4 Pages Per Minute
Simplex configuration: 324 / 505 / 675 / 857
I-Twin / L-Twin / H-Twin: 648 / 1,010 / 1,350 / 1,714
Duty Cycle Million A4 Per Month
Simplex configuration: 2-10 / 3-16 / 5-22 / 6-28
I-Twin / L-Twin / H-Twin: 5-21 / 7-33 / 10-44 / 12-56
PAPER
Print Width
6.5"-21.25" (165-540 mm) (ColorStream 3500 / 3700 / 3900)
6.5"-17" (165-432 mm) (ColorStream 3200 / 3500 / 3700 / 3900)
Page Length
6"- 54"
Paper Width Simplex
6.5"-21.25"
Paper Width Duplex
Simplex configuration: not applicable
I-Twin / L-Twin / H-Twin: 6.5"-21.25"
Paper Weight
60–160 gr/m2
Substrates
Preprinted, inkjet, laser and recycled newspaper
Reel Shafts
70 mm, 3", 5" and 6"
PHYSICAL DATA (ROLL TO ROLL)
Length (without paper)
Simplex configuration: 7,460 mm
I-Twin: 11,950 mm
L-Twin: 10,700 mm
H-Twin: 8,500 mm
Width (without paper)
Simplex configuration: 2,500 mm
I-Twin: 2,500 mm
L-Twin: 8,840 mm
H-Twin: 8,500 mm
Height
1,900 mm
Weight (without paper)
Simplex configuration: 2,500 kg
I-Twin / L-Twin / H-Twin: 5,300 kg
POWER REQUIREMENTS
Europe
Simplex configuration: 33 kW
I-Twin / L-Twin / H-Twin: 33 kW (2 connections)
ENVIRONMENTAL
Temperature
Optimal range 20–26 °C, limited range 16–29 °C
Humidity
Optimal range 40–60%, limited range 30–80%
Operating Noise
Maximum 75 dB
WORKFLOW
Controller
SRA MP third-generation, high-performance blade processors
Printer Data Format
AFPDS, PDF, PCL , Line Data* , LCDS*, Metacode*, PostScript*, PPML*, TIFF*, VIPP*
* Via PRISMAproduction
Print Manager (optimal)
PRISMAproduction®
Connectivity
Gigabit Ethernet
OPTIONS (UNDER REVIEW)
Available Color Configurations
Simplex configuration: 1/0–6/0
I-Twin / L-Twin / H-Twin: 1/1–6/6
MICR and Special Colors
Available for all configurations.
Web Inspection Camera
Available for all configurations.
Rewind Unit
Available for all configurations.
Operator Attention Light
Available for all configurations.
Paper Dust Elimination System
Available for all configurations.
Adobe PDF Print Engine 2.5
Available for all configurations.
Operator Calibration
Available for all configurations.
2-bit Multilevel
Available for all configurations.
