GENERAL PRODUCT INFORMATION
Type
A3 Desktop Type Sheet Fed Scanner
Scanning sensor unit
CMOS CIS 3 Line Sensor
Optical resolution
600dpi
Light source
RGB LED
Scanning side
Front / Back / Duplex
Interface
Dual Interface (High speed USB 2.0 & SCS1-3)
Optional Kofax Hardware VRS (CGA) Card
Dimensions (WxDxH)
Tray Closed: 528 (W) x 563 (D) x 375 (H) mm
Tray Opened: 528 (W) x 861 9D) x 432 (H) mm
Weight
Approx. 39kg
Power requirements
AC220 - 240V (50/60Hz)
Power consumption
Scanning: 125W, Sleep mode: 4.5W (AC 220-240V), Power Turned Off: 0W
Operating environment
10 - 32.5°C (50 - 90.5°F), Humidity: 20 - 80% RH
Environmental compliance
RoHS
SCANNING SPEED (200DPI)
Black and White
130ppm / 260ipm - Landscape speed
Colour
130ppm / 260ipm - Landscape speed
Output resolution
100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400 dpi, 600 x 600dpi
Colour mode
Black and White, Error Diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, 8-bit Greyscale (256-Level), 24-bit Colour
Suggested Daily Duty Cycle
From 60,000 further scans/day
Width
50.8 - 305mm
Length
70 - 432mm
Thickness
Automatic Feeding: 52 - 123gsm (0.06 - 0.15mm)
Bypass Mode: 40 - 255gsm (0.05 - 0.30mm)
Long document mode
3000mm max. (Selectable in MS Windows control panel)
CARD SCANNING
Paper separation
Retard Roller
Feeder capacity
500 sheets(80g/m²)
Selectable 500, 300, 100 sheets & MANUAL/ BYPASS Feeding Mode
Offset Feeding with lockable side guides
SPECIAL FEATURES
Special Features
Auto Page Size Detection, Deskew, Skip Blank Page, Text Oriantation Recognition, Colour Dropout (RGB/Custom)/Enhancement (RGB/Custom), Moire Reduction, Prevent Bleed Through/Remove Background, Punch Hole Removal, MultiStream™, Auto Power On/Off (via USB), Rapid Recovery System, Ultrasonic Double Feed Detection (sensors independently adjustable), Manual/Baypass Feeding, Active Separation Torque Control, Double Feed Retry Mechanism, Job/User Registration Buttons, Verify Scan/Count Only Mode, Buzzer Alarm, Selectable Background (White/Black) Barcode / 2D code recognition, Active threshold
Windows
ISIS /TWAIN Driver (Windows 2000 / XP Pro / XP Home / VISTA / 7 / 8 / 10)
CONSUMABLES
-
Exchange Rolller Kit
Roller Cleaning Sheet
Ink Cartridges (Red, Blue, Green)
BUNDLED SOFTWARE
Windows
CaptureOnTouch Pro
ACCESSORIES
A4 Flatbed 102
Disclaimer
All data is based on Canon standard testing methods except where indicated.
Subject to change without notice.
