GENERAL PRODUCT INFORMATION
Type
Desktop Type Sheet Fed Scanner
Scanning sensor unit
CMOS CIS 1 Line Sensor
Optical resolution
600dpi
Light source
RGB LED
Scanning side
Front / Back / Duplex
Interface
High speed USB 2.0
Dimensions (WxDxH)
Tray Closed : 280mm (W) x 172 (D) x 178 (H) mm
Tray Opened: 280 (W) x 606 (D) x 366.4 (H) mm
Weight
Approx. 3.2kg
Power requirements
AC100 - 240V (50/60Hz)
Power consumption
Scanning 27W or less, Sleep Mode 1.8W or less, Power Turned Off less than 0.5W
Operating environment
10 - 32.5 °C (50 - 90.5 °F), Humidity: 20 - 80% RH
Environmental compliance
RoHS
SCANNING SPEED (200DPI)
Black and White
60ppm / 120ipm
Colour
60ppm / 120ipm
Output resolution
150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi
Colour mode
Black & White/Error Diffusion/ Advanced Text Enhancement (Windows only),Advanced Text Enhancement II, 8-bit Greyscale (256-Level), 24-bit Colour
Suggested Daily Duty Cycle
from 7,000 to 10,000 scans/day
Width
50.8 - 216mm
Length
54 - 356mm
Thickness
27 - 209g/m² (0.04 - 0.25mm)
Long document mode
3000mm Max (selectable in MS Windows control panel)
Card scanning
Width: 53.9mm Length: 85.5mm Thickness: 0.76mm (Embossed Card is supported)
Paper separation
Retard Roller Method
Feeder capacity
75 Sheets (A4, 80g/m²)
SPECIAL FEATURES
Special Features
Automatic Page Size Detection, Deskew, 3- Dimentional Colour Correction, Colour Dropout (RGB), Colour Enhancement (RGB), Auto Colour Detection, Shading Correction, MultiStream, Preset Gamma Curve, Skip Blank Page, Folio Mode, Scan Area Setting, Patch Code, Batch Separation with white blank sheet (Windows only), Edge Enhancement, Moire Reduction, Prevent Bleed Through/Remove Background, Contrast Arrangement, Colour Drift, Adding Black Margin Mode, Colour Elimination, Background Smoothing, Shadow Cropping, Auto Resolution Setting, Stretch Adjustment of Sub-Scanning Direction, Double Feed Release, Thin Paper Mode, Double Feed Detection (Ultrasonic Sensor/ By Length), Separation Retry, Barcode/2D code recognition
BUNDLED SOFTWARE
Windows
ISIS / TWAIN Driver (Windows XP / Vista / 7 / 8 /8.1 / 10)
CaptureOnTouch Pro
Kofax Power PDF
Kofax VRS
Mac
TWAIN Driver
CaptureOnTouch
CONSUMABLES
Exchange Roller Kit
ACCESSORIES
A4 Flatbed 102
NA10 or WA10 Network Adapter
Disclaimer
All data is based on Canon standard testing methods except where indicated.
Subject to change without notice.
